BMW R 1200GS Rallye 2017 User Manual

Rallye motorcycle seat
Remove the Rallye
motorcycle seat
Unlock the seat lock 1 clock-
wise using the ignition key and
keep hold of the ignition key.
Lift the motorcycle seat 2 at
the rear and let go of the igni-
tion key.
Remove the motorcycle seat
and put it to one side on a
clean surface with the uphol-
stery facing down.
Note height adjustment
The front height adjustment 1
must always be adjusted to the
high position (H identification).
The rear height adjustment 1
must always be adjusted to the
low position (L identification).
4
14
z Operation

BMW R 1200GS Rallye 2017 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Torque	125 Nm at 6, 500 rpm
Transmission	6-speed
Curb Weight	244 kg
Final Drive	Shaft drive
Front Tire	120/70 R19
Rear Tire	170/60 R17
Wheelbase	1, 507 mm
Compression Ratio	12.5:1
Fuel System	Electronic fuel injection
Max Power	125 hp at 7, 750 rpm
Fuel Capacity	20 liters
Front Suspension	Telelever, central spring strut
Rear Suspension	BMW Motorrad Paralever
Front Brakes	Dual disc, floating brake discs, diameter 305 mm, 4-piston radial calipers
Rear Brakes	Single 276 mm disc, 2-piston caliper
ABS	BMW Motorrad ABS
Frame	Two-section frame, front- and bolted on rear frame
Length	2, 210 mm
Height	1, 450 mm
Clutch	Wet clutch, hydraulically operated
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
