BMW R 1200GS Rallye 2017 User Manual

Clamp to silencer and
exhaust manifold
22 Nm
Position the cover 2 and install
the screws 1.
Cover on silencer/ex-
haust manifold
Tightening sequence: 1. ex-
haust manifold, 2. silencer
(top), 3. silencer (bottom)
5 Nm
Riding
Riding with off-road tyres
The R 1200 GS can be equipped
with off-road tyres for off-road
applications.
NOTICE
It is possible to adapt the tyre
pressure accordingly when rid-
ing with off-road tyres in rough
terrain.
We recommend you switch off
RDC when you have changed
the tyre pressure to prevent in-
correct on-board computer noti-
fications.
Maximum speed with
knobbly tyres or winter
tyres
DANGER
Maximum speed of the mo-
torcycle is higher than the
permissible maximum rated
speed of the tyres
Risk of accident due to tyre dam-
age at high speed
Comply with the tyre-specific
speed restrictions.
Always bear the maximum per-
missible speed of the tyres in
mind when riding a motorcycle
fitted with knobbly tyres or winter
tyres.
Affix a label stating the maximum
permissible speed to the instru-
ment panel in the rider's field of
vision.
5
22
z Off-road use

BMW R 1200GS Rallye 2017 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Torque	125 Nm at 6, 500 rpm
Transmission	6-speed
Curb Weight	244 kg
Final Drive	Shaft drive
Front Tire	120/70 R19
Rear Tire	170/60 R17
Wheelbase	1, 507 mm
Compression Ratio	12.5:1
Fuel System	Electronic fuel injection
Max Power	125 hp at 7, 750 rpm
Fuel Capacity	20 liters
Front Suspension	Telelever, central spring strut
Rear Suspension	BMW Motorrad Paralever
Front Brakes	Dual disc, floating brake discs, diameter 305 mm, 4-piston radial calipers
Rear Brakes	Single 276 mm disc, 2-piston caliper
ABS	BMW Motorrad ABS
Frame	Two-section frame, front- and bolted on rear frame
Length	2, 210 mm
Height	1, 450 mm
Clutch	Wet clutch, hydraulically operated
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
