Automatic climate control*
1 Airflow directed toward the wind-
shield and side windows
2 Airflow for the upper body
The side rotary dials provide infi-
nitely-variable regulation of the air
supply, while the levers change the
airflow direction. The center rotary
dial controls the temperature of the
air as it flows out. Refer to page 111
3 Front footwell ventilation
4 Rear footwell ventilation
5 Air flow for the upper body in the
rear seat 110
6 Automatic air distribution 108
7 Individual air distribution 108
8 Temperature control –
left-hand side 108
9 Display for temperature and air
supply 109
10 Temperature control –
right-hand side 108
11 To defrost windshield and side
windows 109
12 Air conditioner 109
13 Automatic recirculated air control
(AUC) 110
14 Rear window defroster 73, 110
15 Air supply 109
16 Maximum cooling 109
or using up residual heat 110
17 Air grille for interior temperature
sensor – please keep clear and
unobstructed
