3. Press the button, arrow 1, down, press the
catches, arrows 2, outward slightly, and re‐
move the bulb holder.
4. Apply gentle pressure to the P21W bulb
while turning it to the left for removal and
replacement.
Remove the W16W bulb and replace.
5. Re-engage the bulb holder so that it audi‐
bly clicks into place.
6. Remount the side panel.
Brake Force Display
Follow the general instructions on lamps and
bulbs, refer to page 295.
1.
Carefully remove the cover in the tailgate
panel with a screwdriver.
2. Push the catch on the bulb holder to the
left, arrow, and remove it.
3. Apply gentle pressure to the bulb while
turning it to the left for removal and re‐
placement.
4. Re-engage the bulb holder so that it audi‐
bly clicks into place.
5. Before installing the cap, unclip the cargo
area lamp.
Then lay the cap on its upper side and
close it, refer to arrow.
6. Position the cargo area lamp and clip it in,
refer to arrow.
License plate lamps
Follow the general instructions on lamps and
bulbs, refer to page 295.
These lamps are made using LED technology.
Contact your service center in the event of a
malfunction.
Center brake lamp
Follow the general instructions on lamps and
bulbs, refer to page 295.
This lamp uses LED technology for operation.
Contact your service center in the event of a
malfunction.
Seite 298
Mobility Replacing components
298
Online Edition for Part no. 01 40 2 918 440 - III/13
