Turn signal
Follow the general instructions on lamps and
bulbs, refer to page 295.
1. Open the side panel in the cargo area.
2. Remove the first aid kit and warning trian‐
gle if necessary.
3. Remove bulb holder along with bulb and
replace.
4. Install in the reverse order.
Backup lamp
Follow the general instructions on lamps and
bulbs, refer to page 295.
1.
Open the side panel in the cargo area.
2. Remove the first aid kit and warning trian‐
gle if necessary.
3. Remove bulb holder along with bulb and
replace.
4. Install in the reverse order.
Brake force display
Follow the general instructions on lamps and
bulbs, refer to page 295.
1. Carefully remove the cover in the tailgate
panel with a screwdriver.
2. Rotate the bulb socket to the left and re‐
move.
3. Apply gentle pressure to the bulb while
turning it to the left for removal and re‐
placement.
4. Insert the bulb socket in the tailgate and
engage it.
5. Replace the cover.
License plate lamps
Follow the general instructions on lamps and
bulbs, refer to page 295.
These lamps are made using LED technology.
Contact your service center in the event of a
malfunction.
Center brake lamp
Follow the general instructions on lamps and
bulbs, refer to page 295.
Seite 301
Replacing components Mobility
301
Online Edition for Part no. 01 40 2 918 440 - III/13
