Feature Codes & Defaults
Feature
Feature
Code
Data Default
Pre-Announce /
Confirmation Tone
Handset & Outputs
Handset only
Outputs only
Inhibit
Beep
Chime
01
02
03
04
05
06
01
05
Override Tone
Disable
Enable
08
09
08
Trunk Disconnect
Disable
Enable
14
15 15
Timers
Default Timer
VOX Timer
50
51
00 - 99
0 - 9
03
6
Tone Trigger
Slow Whoop Follow Contact
Tone Follow Contact
2 Sec Burst
3 Sec Burst
4 Sec Burst
5 Sec Burst
6 Sec Burst
7 Sec Burst
Double Chime
Double Chime Follow
Contact
20
21
22
23
24
25
26
27
28
29
23
Night Ring
Simulated Ring
Chime
31
32
31
Setup Tone
Turn On
Turn Off
00
Hang Up
Reset
Reset Default 99
Destination
Tone
DTMF Block
Disabled
Enabled
40
41 41
Aux Relay
Response
Override Disabled
Override Enabled
60
61 61
Tone Trigger Disabled
Tone Trigger Enabled
62
63 63
Page Disabled
Page Enabled
64
65 65
Night Ring Disabled
Night Ring Enabled
66
67 67
Delay
No Delay
68
69 69
Priority-Driven
Event-Driven
70
71 71
Notes to Feature Codes
Note 1 - The data digits
represent time in 10's of
seconds, i.e. "01" = 10 seconds.
Entering "00" will disable the
timer.
Note 2 - This single data digit
indicates VOX delay time in
seconds. Entering "0" will
disable the timer.

Bogen UTI1 Specifications

Impedance and Levels

input impedance	600 ohms
bgm input impedance	20k ohms
output impedance	8 ohms

Power

dc output	1A @ 24V DC
voltage	120V AC
current	0.5A

Operating Environment

temperature range	0 to 104º F (-18 to 40º C)
humidity	0 to 85% non-precipitating

Weight and Dimensions

dimensions	12-[1]/4" W x 5-[1]/4" H x 2-[1]/2" D
product weight	5 lb.
