Analog detectors and bases Notes | en 5
Bosch Security Systems, Inc. Installation Guide 2018.08 | 6.0 | F.01U.123.589
1 Notes
This document covers mounting and wiring for the FAP-440 Series bases and detector heads.
For proper installation, read and understand NFPA-72, The National Fire Alarm Code before
installation.
Notice!
Install the device according to this Installation Guide, NFPA 72, Local Codes and the Authority
Having Jurisdiction (AHJ). Failure to follow these procedures may cause the device to not
function properly. Bosch Security Systems is not responsible for any devices that are
improperly installed.
Caution!
Do not remove the dust cap until all onsite construction work has been completed and the
fire panel network has been commissioned.
2 Product Types
Product Type Description
FAP-440 Analog Photoelectric Detector
FAP-440-D Analog Dual-Photoelectric Detector
FAP-440-T Analog Multisensor Detector Photo/Heat
FAP-440-DT Analog Multisensor Detector Dual-Photo/Heat
FAP-440-TC Analog Multicriteria Detector Photo/Heat/CO
FAP-440-DTC Analog Multicriteria Detector Dual-Photo/Heat/CO
FAH-440 Analog Heat Detector, configurable fixed temperature/rate-of-rise
FAA-440-B4 Analog Standard Base 4 inches
FAA-440-B6 Analog Standard Base 6 inches
FAA-440-B4-ISO Analog Isolator Base 4 inches
FAA-440-B6-ISO Analog Isolator Base 6 inches
Table2.1: List of Products
Notice!
The CO sensor detects carbon monoxide as a by-product of combustion. It has not been
evaluated for its ability to detect hazardous CO gas. Do not use the FAP-440-TC and
FAP‑440‑DTC as stand-alone CO detector.
