ACS 753, ACS 763, ACS 863 Service Manual
SP00D00609 2018-03-26Robert Bosch GmbH
21
Introduction
ACS 763 ACS 863 ACS 753
Flush Port Yes Yes Yes
RefrigerantIdentier Optional as external
device
Embedded -
Flush Kit Optional for R1234yf Optional for R1234yf Optional for R134a
N2H2 Yes, embedded port
for external tank
Yes, embedded port
for external tank
Yes, embedded port
for external tank
Wireless Wi/BT usb dongle
into scope of delivery
Wi/BT usb dongle
into scope of delivery
Wi/BT usb dongle
into scope of delivery
External source cylinder
adapters
1234YF LS J639
MALE TO
W21.8-1/14LH
ADAPTER
ADAPTER 1234YF
LS J639 MALE
M26.2x1.8
ADAPTER 1234YF
LS J639 MALE
12.7 mm ACME16
1234YF LS J639
MALE TO
W21.8-1/14LH
ADAPTER
ADAPTER 1234YF
LS J639 MALE
M26.2x1.8
ADAPTER 1234YF
LS J639 MALE
12.7 mm ACME16
QUICK COUPLER
FOR COMMERCIAL
TANK 1/4” SAE
TANK ADAPTER
R134a - 21,8-14
G/1/4
Compressor
Power 1/4 HP 1/4 HP 1/4 HP
Displacement 8.85 cm
3
8.85 cm
3
8.85 cm
3
Recovery performance
(maximum, liquid phase)
- - -
Power Supply 230 Vac/1 50/60 Hz 230 Vac/1 50/60 Hz 230 Vac/1 50/60 Hz
Vacuum Pump
Free Air Displacement 170 l/min (6 CFM) 170 l/min (6 CFM) 170 l/min (6 CFM)
Ultimate Vacuum (min) 40 microns 40 microns 40 microns
Oil Capacity 700 ml 700 ml 700 ml
Type 2 stages oil bath 2 stages oil bath 2 stages oil bath
Power Supply 230 Vac/1 50/60 Hz 230 Vac/1 50/60 Hz 230 Vac/1 50/60 Hz
Scales
ISV scale accuracy ±15 g ±15 g ±15 g
Bottle scales accuracy ±2 g ±2 g ±2 g
