Chain saw AKE 3000 AKE 30-17 S AKE 3500 AKE 35-17 S AKE 4000 AKE 40-17 S
Part number 0 600 836 4.. 0 600 836 0.. 0 600 836 5.. 0 600 836 1.. 0 600 836 6.. 0 600 836 2..
Tool-less chain
tensioning (SDS) –• –• –•
Rated power 1600 W 1700 W 1600 W 1700 W 1600 W 1700 W
Chain speed (no load) 12 m/s 12 m/s 12 m/s 12 m/s 12 m/s 12 m/s
Chainbar length 30 cm 30 cm 35 cm 35 cm 40 cm 40 cm
Nose sprocket –– •• ••
Kick back braking time 0.1 sec 0.1 sec 0.1 sec 0.1 sec 0.1 sec 0.1 sec
Run down brake •• •• ••
Chain type 90 SG 90 SG 90 SG 90 SG 90 SG 90 SG
Oil reservoir capacity 200 ml 200 ml 200 ml 200 ml 200 ml 200 ml
Automatic oiler •• •• ••
Metal gripping teeth •• •• ••
Weight 4.2 kg 4.2 kg 4.3 kg 4.3 kg 4.4 kg 4.4 kg
Protection class / II / II / II / II / II / II
The chain saw is intended for sawing of tree trunks,
branches, wooden beams, planks, etc. Cuts can be
sawed with or across the grain.
This manual gives instructions on the correct assembly
and safe use of your chain saw. It is important that you
read these instructions carefully.
Carefully remove the machine from its packaging and
check for complete contents:
– Chain saw
– Cover plate
– Chain
– Chain bar
– Chain guard
– Chain oil (50 ml)
– Adjustment tool (AKE 3000/3500/4000)
– Operating instructions/Spare parts list
When parts are missing or damaged, please contact your
dealer.
1 Rear handle
2 On/off-switch
3 Safety button
4 Oil filler cap
5 Activation lever for kick back brake (hand guard)
6 Front handle
7 Deactivation mark for kick back brake
8 Nose sprocket (AKE 3500/35-17 S/4000/40-17 S)
9 Chain guard
10 Chain
11 Chain bar
12 Gripping teeth
13 Tensioning ring (red)
(AKE 30-17 S/35-17 S/40-17 S)
14 Locking knob (AKE 30-17 S/35-17 S/40-17 S)
15 Cover plate
16 Locking nut (AKE 3000/3500/4000)
17 Chain tensioning catch
(AKE 30-17 S/35-17 S/40-17 S)
18 Fastening bolt
19 Guide fins for chain bar
20 Oil outlet
21 Symbol for rotation and cutting direction
22 Drive sprocket
23 Chain tensioning peg (AKE 3000/3500/4000)
24 Chain tensioning screw (AKE 3000/3500/4000)
25 Mains plug**
26 Chain catch bolt
**Country specific
Not all of the accessories illustrated or described are
included as standard delivery.
Product Specification
Intended Use
Introduction
Delivered Items
Operating Controls
