The product is intended for the cutting of grass and
weeds under bushes, as well as on slopes and
edges that can not be reached with the lawn mower.
Intended Use is related to operation within 0 °C and
40 °C ambient temperature.
This manual gives instructions on the correct as-
sembly and safe use of your machine. It is important
that you read these instructions carefully.
Carefully remove the machine from its packaging
and check that you have all the following items:
– Trimmer
– Cutting guard
– Cutting disc
– Blades
– Battery charger
– Operating instructions
When parts are missing or damaged, please contact your
dealer.
1
On/Off switch
2
Handle
3
Guide handle
4
Shaft, upper
5
Shaft, lower
6
Trimmer head
7
Ventilation slots
8
Cutting guard
9
Battery
10
Battery charger
11
Charging compartment
12
LED indicator
13
Mains plug*
14
Serial No
* Country specific
Not all of the accessories illustrated or described are
included as standard delivery.
Product Specification
Trimmer
ART 23 EASYTRIM ACCU/
ART 2300 EASYTRIM ACCU
ART 26 EASYTRIM ACCU/
ART 2600 EASYTRIM ACCU
Part number (Typ)
3 600 H78 H.. 3 600 H78 J..
No-load speed [rpm] 9 500 9 000
Cutting circle [cm] 23 26
Weight (without optional extras) [kg] 1.9 2.0
Serial Number See serial No
14
(rating plate) on machine.
Battery type
NiCd NiCd
Battery order number
2 607 335 533 2 607 335 533
Battery Voltage [V] 14,4 14,4
Battery rating [Ah] 1.5 1.5
Charging time (empty battery) [min] 250 250
Battery Charger
AL 1404 AL 1404
Order number
2 607 225 .. 2 607 225 ..
Charging current [A] 0.4 0.4
Allowable charging temperature
range [°C] 0 – 45 0 – 45
* Charge time based on a battery charger input voltage of 230 V.
Intended Use
Introduction
Delivered Items
Operating Controls
F016 L70 455 • 06.08
