Before any work on the machine itself, re-
move battery from machine.
Note: To ensure long and reliable service, carry out
the following maintenance regularly.
Regularly check for obvious defects such as loose
fixings, and worn or damaged components.
Check that covers and guards are undamaged and
correctly fitted. Carry out necessary maintenance or
repairs before using.
If the trimmer should happen to fail despite the care
taken in manufacture and testing, repair should be
carried out by an authorized customer service agent
for Bosch garden products.
For all correspondence and spare parts orders, al-
ways include the 10-digit part number (TYP) from
the nameplate of the machine!
Before any work on the machine itself, re-
move battery from machine.
To remove the worn blade
16
push in direction of the
arrow until it snaps off the pivot
17
.
Clean the pivot
17
of any residual plastic/debris with
a sharp knife.
To refit the new blade
16
place the eyelet over the
pivot
17
and pull outwards until it snaps into place.
Note:
Only use Bosch replacement blades. They
have been developed specially for improved cutting
performance. The use of other cutter blades will lead
to a deterioration in performance and possible dam-
age to the product.
Stop and remove battery from product. En-
sure battery is removed before storage.
Clean the exterior of the machine thoroughly using a
soft brush and cloth. Do not use water, solvents or
polishes. Remove all grass and debris, especially
from the ventilation slots
7
.
Turn the machine on its side and clean the cutting
guard
8
inside. If grass cuttings are compacted, re-
move with a wooden or plastic implement.
Battery should be stored between 0 – 45 °C; incor-
rect storage could result in the battery being dam-
aged.
Maintenance
Blade Maintenance
D
After Trimming/Storage
F016 L70 455 • 06.08
F016 L70 455 - GB Seite 4 Dienstag, 29. August 2006 1:48 13
