Charging Procedure
The charging procedure starts as soon as the mains
plug
13
is plugged into the socket and the battery
9
is inserted into the charging compartment
11
.
The green LED 12 is not a charge control indica-
tor!
When the green LED is lit, it indicates that a
charging current flows.
After the end of the charging process (approx. 3 h–
4 h), pull the mains plug of the battery charger from
the socket and remove the battery.
The battery should not be charged for longer
than 5.5 hours.
A temperature increase of the battery indicates that
it is fully charged.
Charging Advice
With continuous or several repetitive charging cy-
cles without interruption, the charger can warm up.
This is not harmful and does not indicate a technical
defect of the unit.
A battery that is new or has not been used for a
longer period does not develop its full capacity until
after approximately 5 charging/discharging cycles.
Leave such batteries in the charging compartment
until they have clearly warmed up.
A significantly reduced working period after charging
indicates that the batteries are used and must be re-
placed.
Do not connect the battery before product
is completely assembled.
Ensure product is assemble in the following or-
der:
Assemble trimmer shaft
Push the upper shaft
4
and lower shaft
5
together
until a click can be heard.
Note:
Once the upper and lower shaft is assembled
it can not be disassembled. Ensure internal cable is
not trapped or twisted.
Mounting the Cutting Guard
Place the cutting guard
8
on the trimmer head
6
.
➊
Hook the guard onto trimmer head and push until
secure fitting.
➋
Push rear of guard until secure (click).
Fitting Cutting Disc/Fitting Blade
Press cutting disc
15
onto drive adaptor as shown
(click).
Fit the blade, place the blade
16
over the pivot
17
and pull outwards until it snaps into place.
Remove stones, loose pieces of wood and
other objects from the cutting area.
The blade continues to rotate for a few seconds
after the trimmer is switched off. Allow the mo-
tor/blade to stop rotating before switching “on”
again.
Do not rapidly switch off and on.
Switching On and Off
Press switch
1
and hold depressed. Release
switch
1
for switching off.
Cutting Grass
Move the trimmer left and right, keeping it well away
from the body.
The trimmer can efficiently cut grass up to a height
of 15 cm. Cut taller grass in stages.
Cutting Around Trees and Bushes
Carefully cut around trees and bushes so that they
do not come into contact with the cutting line.
Plants can die if you damage the bark.
Battery duration
Battery duration is dependent on the working condi-
tions:
light conditions:
up to 500 metres
medium conditions:
up to 300 metres
tough conditions:
up to 50 metres
For Your Safety
Warning! Switch off, remove battery from ma-
chine before adjusting or cleaning.
The blade continues to rotate for a few sec-
onds after the trimmer is switched off.
Caution – do not touch rotating blade.
Product Assembly
A
B
Cutting and Edging
C
D
