2. User instructions
2.1 Important information
You can find important information on using the tools in
the ESI[tronic] repair instructions for type CP1/CP1H
common-rail high-pressure pumps.
Read the instructions carefully before using the tools,
and observe them at all times.
2.2 Safety instructions
Safety instructions are provided:
¶ In the ESI[tronic] repair instructions for type
CP1/CP1H common-rail high-pressure pumps.
¶ In brochure 1689989246 "Service tools – Important
information and safety instructions."
Read the safety instructions carefully before using the
tools, and observe them at all times.
2.3 Intended use
The tools in tool set 0 986 614 360 are exclusively
intended for testing and repairing type CP1/CP1H
common-rail high-pressure pumps.
! Failure to observe this may lead to injury and
damage.
2.4 Training
Only instructed and trained qualified personnel
may test and repair type CP1/CP1H common-rail
high-pressure pumps. We recommend conducting
a user training. For further information see:
www.bosch-training-solutions.com
3. Product description
3.1 Scope of delivery
i
Tools marked with an asterisk (*) are part of the
scope of delivery of supplementary equipment set
0986613750. Additionally, the supplementary
equipment set contains a tool holder for the tool
board and a spacer sleeve. For more information,
see Sec.4.
Designation Part number
Tool board, unloaded
(with cover and strip)
–
Mounting flange 0 986 612 806
Removal device 0 986 612 397
Adjustment screw (2items) 0 986 612 501
Extractor device 0 986 611 821
Sealing plug 0 986 612 413
Taper sleeve (3items) 0 986 612 801
Removal device 0 986 612 820
Press-in tool 0 986 612 503
Guide pin 0 986 612 504
Guide pin 0 986 612 423
Extractor 0 986 613 165
Installation tool 0 986 612 911
Mounting mandrel* (1.5 mm)
1)
0 986 613 708
Mounting mandrel* (2.4 mm)
1)
0 986 613 456
Press-in tool* (13 mm)
1)
0 986 613 731
Press-in tool* (17 mm)
1)
0 986 613 742
Extractor* 0 986 610 906
Press-in tool 0 986 612 200
Mounting sleeve 0 986 612 884
Mounting sleeve 0 986 611 851
Mounting sleeve 0 986 611 815
Mounting sleeve 0 986 612 787
Guide pin (2items) 0 986 612 598
Removal device 0 986 612 062
Mounting sleeve 0 986 612 779
Mounting sleeve 0 986 611 706
Press-in tool 0 986 612 970
Press-in tool 0 986 612 205
Press-in tool 0 986 612 201
Press-in tool 0 986 612 886
Press-in tool 0 986 612 904
Mounting mandrel 0 986 611 675
Mounting mandrel 0 986 611 665
Press-in tool* (1.5 mm)
1)
0 986 613 716
Press-in tool* (11.4 mm)
1)
0 986 613 722
Press-in tool* (25.2 mm)
1)
0 986 613 753
Operating instructions –
1)
The dimension (in mm) on the tool is the press-in dimension of
the rod filter or cap.
