5. Maintenance
5.1 Checking the tools for wear and
damage
Prior to use, check the tools for wear and damage.
! Always replace worn or damaged tools. Worn or
damaged tools may cause injuries and damage
components.
5.2 Cleaning tools
After use:
1. Use a lint-free workshop rag to rub the tools clean.
2. Place the clean tools on the tool board.
5.3 Spare and wearing parts
Designation Part number
Mounting flange
<)
0 986 612 806
Removal device
<)
0 986 612 397
Adjustment screw
<)
(2items) 0 986 612 501
Extractor device
<)
0 986 611 821
Sealing plug 0 986 612 413
Removal device 0 986 612 820
Press-in tool 0 986 612 503
Guide pin 0 986 612 504
Guide pin 0 986 612 423
Extractor
<)
0 986 613 165
Installation tool 0 986 612 911
Mounting mandrel 0 986 613 708
Mounting mandrel 0 986 613 456
Press-in tool 0 986 613 731
Press-in tool 0 986 613 742
Extractor
<)
0 986 610 906
Press-in tool 0 986 612 200
Mounting sleeve 0 986 612 884
Mounting sleeve 0 986 611 851
Mounting sleeve 0 986 611 815
Mounting sleeve 0 986 612 787
Guide pin
<)
(2items) 0 986 612 598
Removal device 0 986 612 062
Mounting sleeve 0 986 612 779
Mounting sleeve 0 986 611 706
Press-in tool 0 986 612 970
Press-in tool 0 986 612 205
Press-in tool 0 986 612 201
Press-in tool 0 986 612 886
Press-in tool 0 986 612 904
Mounting mandrel 0 986 611 675
Mounting mandrel 0 986 611 665
Press-in tool 0 986 613 716
Press-in tool 0 986 613 722
Press-in tool 0 986 613 753
<)
Wearing part
7. Technical data
Dimensions and weight of the tool board.
Function Specification
Tool board weight Approx. 12kg
Tool board dimensions
R Width
R Height
R Depth
492mm
414mm
128mm
The 0 986 614 360, its accessories and
packaging should be recycled in an environ-
mentally friendly manner.
¶ Do not dispose of the 0 986 614 360 in
general trash.
6. Decommissioning
6.1 Change of location
¶ If the 0 986 614 360 is passed on, all the documen-
tation included in the scope of delivery must be
handed over together with the unit.
¶ The 0 986 614 360 is only ever to be transported in
the original or equivalent packaging.
6.2 Disposal and scrapping
¶ Dismantle the 0 986 614 360 and sort out and dis-
pose of the different materials in accordance with
the applicable regulations.
