Overview
Overview
(Figures B to E on the fold-out pages)
1 Appliance door
a Recessed grip (for opening the door)
b Drip plate
2 Control panel (see next page)
a Control ring
b Information display
c Touch display (left and right)
3 Outlet system (co󰀨ee, milk, hot
water), height-adjustable
a Cover
4 Milk system
a Snap lever
b Beverage outlet (upper part,
lower part)
c Milk tube (2 pieces)
d Connecting element, metal (for
magnet holder)
5 Mains switch J (power supply)
6 Accessory drawer
(for quick reference guide and
accessories)
a Quick reference guide
b Measuring spoon
c Water hardness strip
d Milk tube (set)
7 Removable water tank
a Lid for water tank
8 Removable bean container
a Lid for bean container
9 Slide regulator for grinding degree
setting
10 Magnet holder (for connecting
element)
11 Removable drawer
(for ground co󰀨ee/cleaning tablet)
12 Holder (for milk tube)
13 Protective cover (for brewing unit)
14 Brewing unit
a Locking mechanism
b Cover
15 Eject lever
16 Removable Drip tray
a Drip tray cover
b Co󰀨ee grounds container
17 Collecting tray
18 Holder
a Suction pipe
19 Rating plate (E number, FD)
20 Shelf with sensor (for milk container)
21 Milk container
a Stainless steel container
b Lower part of the lid
c Upper part of the lid
F
Further information about the appli-
ance, such as how to change the
opening angle of the door, can be
found in the assembly instructions�
Controls
The appliance features user-friendly menu
navigation to ensure that operation is as
easy as possible while at the same time
o󰀨ering a wide range of functions. That
means a range of options can be selected
with just a few operating steps�
Mains switch J
The power switch J (with the door
open) is used to switch the appliance on, or
to switch it o󰀨 fully (power supply o󰀨).
F
Important: Do not press the mains
switch while the appliance is in use�
Switch off the appliance only when
it is in energy saving mode, so that it
can rinse automatically�
Control panel (touch eld)
F
Important: These operating
instructions refer to several models�
In some models I and C are
touchscreen elements�
I on/o󰀨
Press I to switch on the appliance or
put it into energy saving mode� The appli-
ance is rinsed automatically�
The appliance does not rinse if:
■ if it is still warm when switched on, or
■ if no co󰀨ee was dispensed before it was
switched o󰀨.
The appliance is ready for use as soon as
the symbols for the drinks selection appear
on the display�

Bosch CTL636ES6 Specifications

General

Product type	Espresso machine
Built-in grinder	Yes
Capacity in cups	- cups
Milk adding type	Automatic
Number of spouts	1
Coffee input type	Coffee beans
Coffee maker type	Fully-auto
Appliance placement	Built-in
Water tank capacity	2.4 L
Coffee beans capacity	500 g
Maximum operating pressure	19 bar
Reservoir for brewed coffee	-
Cord length	1.7 m
Display type	TFT
Product color	Black, Stainless steel
AC input voltage	220–240 V
AC input frequency	50 - 60 Hz
Package depth	670 mm
Package width	475 mm
Package height	545 mm
Package weight	22420 g

Weight and Dimensions

Depth	375 mm
Width	594 mm
Height	455 mm
Weight	19440 g
Installation compartment depth	356 mm
Installation compartment width	558 mm
Installation compartment height	449 mm
