8 | English
u Have the measuring tool serviced only by a qualified specialist using
only original replacement parts. This will ensure that the safety of the
measuring tool is maintained.
u Do not let children use the laser measuring tool unsupervised. They
could accidentally dazzle someone.
u Do not use the measuring tool in explosive atmospheres which con-
tain flammable liquids, gases or dust. Sparks may be produced inside
the measuring tool, which can ignite dust or fumes.
Product Description and Specifications
Please observe the illustrations at the beginning of this operating manual.
Intended Use
The measuring tool is intended for determining and checking horizontal and
vertical lines.
The measuring tool is suitable for indoor use.
Product Features
The numbering of the product features shown refers to the illustration of the
measuring tool on the graphic page.
(1)
Laser beam outlet aperture
(2)
Status indicator
(3)
On/off button/operating mode button
(4)
Laser warning label
(5)
Pendulum lock switch
(6)
1/4" screw of the holder
(7)
Locking screw of the holder
(8)
Fastening screw of the holder
(9)
Holder
(10)
Battery compartment cover
(11)
Battery compartment cover locking mechanism
(12)
1/4" tripod mount
(13)
Serial number
1 609 92A 58R | (04.03.2020) Bosch Power Tools
