6/12 DBD | Pressure relief valve
Bosch Rexroth AG, RE 25710, edition: 2016-07
1.1 Adjustment type "S", internal hexagon SW5
1.2 Adjustment type "H", hand wheel
2 Lock nut SW17, tightening torque M
A
=10+
5
Nm
3 Hexagon SW17, tightening torque when screwing in
M
A
= 23
±2
Nm
4 Embossed type designation
① = Main port 1 (P)
② = Main port 2 (T)
Dimensions
(dimensions in mm)
