CC408 | Quick Reference Guide | 3. Programming Parameters EN | 15
Bosch Security Systems | 6/04 | 4998152468B
3.11.2 continued
Event
Code
Description
1 10 Codepad panic alarm
1 11 Codepad duress alarm
1 12 Access denied (code retries)
1 13 Reserved
1 14 Horn speaker (Output 1 only)
1 15 Sirens running
2 0 Strobe
2 1 Silent alarm
2 2 Alarm in STAY Mode
2 3 Alarm in AWAY Mode
2 4 System fault
2 5 Fire alarm (resetting)
2 6 Fire alarm (latching)
2 7 Fire alarm (verification)
2 8 Remote Control 1
2 9 Remote Control 2
2 10 Remote Control 3
2 11 Radio Control Output 1
2 12 Radio Control Output 2
2 13 Radio Control Output 1 – not in AWAY
Mode
2 14 Radio Control Output 2 – not in AWAY
Mode
2 15 Communications fail after three attempts
3 0 Communications fail
3 1 Dialler disabled
3 2 Dialler active (on-line)
3 3 Ring detect
3 4 Reserved
3 5 Mimic zone 1
3 6 Mimic zone 2
3 7 Mimic zone 3
3 8 Mimic zone 4
3 9 Mimic zone 5
3 10 Mimic zone 6
3 11 Mimic zone 7
3 12 Mimic zone 8
4 0 Reserved
4 1 Reserved
4 2 Reserved
4 3 Reserved
4 4 Reserved
4 5 Chime
4 6 Zone not sealed
4 7 Zone not sealed after exit time
4 8 Reserved
4 9 AC mains cycle (60 Hz or 50 Hz)
4 10 Area 1 – zone unsealed
4 11 Area 2 – zone unsealed
4 12 Reserved
4 13 Reserved
4 14 Reserved
4 15 Reserved
3.11.2 continued
Event
Code
Description
5 0 Reserved
5 1 Reserved
5 2 Area 1 in alarm
5 3 Area 2 in alarm
5 4 Reserved
5 5 Reserved
5 6 Area 1 armed
5 7 Area 2 armed
5 8 Reserved
5 9 Reserved
5 10 Area 1 disarmed
5 11 Area 2 disarmed
5 12 Reserved
5 13 Reserved
5 14 Any areas armed
5 15 Any areas disarmed
6 0 Area 1 codepad data terminal
6 1 Area 2 codepad data terminal
3.11.3 Polarity (Modes)
Option Description
0 Disabled
1 Normally open, going low
2 Normally open, pulsing low
3 Normally open, one shot low
4 Normally open, one shot low (reset)
5 Normally open, one shot low (re-trigger)
6 Normally open, latching low
7 Reserved
8 Normally low, going open
9 Normally low, pulsing open
10 Normally low, one shot open
11 Normally low, one shot open (reset)
12 Normally low, one shot open (re-trigger)
13 Normally low, latching open
3.11.4 Time Base
Option Description
1 200 milliseconds
2 1 second
3 1 minute
4 1 hour
3.11.5 Time Base Multiplier
Enter a value between 01 and 99.
3.11.6 One Shot Mode
When you program the output polarity as one
shot, the time base is multiplied by the time base
multiplier. For example, if the time base = 2 and
the multiplier = 05, the output operates for 10
seconds.
