Application Considerations | 21Revised 08/14
8 733 914 818 (2014/08)SV Heat Pump Series
Geothermal Closed Loop Systems
Operation of an SV Series unit on a closed loop
application requires the extended range option.
Utilizing Ground Loop Pumping Package (GLP),
makes the installation easy. Anti-freeze solutions
must be utilized when low loop temperatures are
expected to occur. Refer to the installation
manuals for more specific instructions. See Figure
#15
Figure # 15 Earth Coupled Application
CAUTION: Closed loop and pond
applications require specialized design
knowledge. No attempt at these
installations should be made unless the
dealer has received specialized training.
Note: See Figure #5 for Condensate Drain
