FAN MOTOR OPTIONS
Permanent Split Capacitor Motors (PSC)
The standard motor for all SV series heat pumps is
a PSC motor. For all models the supplied motor is
a three speed motor. If a speed change is required,
follow the instructions below:
1. Disconnect power to the heat pump.
2. For units with leaded motors, remove the front
access cover.
3. Remove the fan speed wire from the fan relay.
Clip the ¼” quick connect from the lead and
cap the unused lead.
4. Uncap the desired fan speed wire and
terminate with a ¼” quick connect. Connect to
the fan relay.
5. If the motor is a 460 V motor and the speed is
changed from high to medium or low, connect
the high speed motor lead to the orange
intermediate winding lead instead of simply
capping it.
Refer to the PSC motor performance tables for
heat pump blower performance with the PSC
motor option.
Table 5: PSC Motor Performance Data
Model
Fan
Speed
Rated
Airflow
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00 1.10 1.20
SV-007
Low 370 340 295 250 - -------
Med
300 390 360 330 300 260 -------
Hi
410 380 350 315 280 210 - -----
SV-009
Low 370 340 295 250 - -------
Med
390 360 330 300 260 -------
Hi
350 410 380 350 315 280 210 - -----
SV-012
Low 300 290 290 300 - -------
Med
380 380 360 330 290 -------
Hi
400 420 400 380 360 340 320 - -----
SV-015
Low 320 300 280 ---------
Med
380 370 360 340 330 -------
Hi
500 520 500 480 460 430 400 340 -----
SV-018
Low 630 590 560 ---------
Med
650 810 790 760 730 680 590 - -----
Hi
1010 970 920 870 800 680 530 -----
SV-024
Low 650 610 570 540 510 -------
Med
830 820 800 770 720 620 - -----
Hi
850 1050 1000 950 910 840 710 570 -----
SV-030
Low 740 730 700 660 610 -------
Med
830 810 770 730 680 620 - -----
Hi
950 1000 950 900 830 750 690 630 -----
SV-036
Low 1290 1250 1200 1150 1080 1000 - -----
Med
1410 1350 1290 1220 1150 1060 900 -----
Hi
1200 1500 1440 1370 1290 1210 1120 1000 900 - ---
To Next Page
