You have purchased a Bosch T4B Miter Saw
Stand, designed for job site use. This unit
sets up and folds quickly, and is easily
loaded or unloaded by one person into a
truck.
"! #
Phillips screwdriver, 10 MM open end
wrench, 13 MM open end wrench, 17 MM
open end wrench, and adjustable wrench.
%#!!"!
" !$!"
Sort out and account for all parts to make
sure that you have all necessary materials to
assemble your stand. Do not discard packing
material until all parts are accounted for.
"" !$!"
""!
9*2
9> &79*8(7.59.43
A (1) Main Frame
B (1) Base Tube
C (1) Kick Bar
D (1) Right Wheel/Leg Assembly
E (1) Left Wheel/Leg Assembly
F (1) Support Link Assembly
G (1) Rail Assembly/Support Leg
H (2) Tool Mount Assemblies
7*88*2'1>
-3-
