MAIN PART LIST
Item Number Description Part Number Qty. Note
1 Dpdt Slide Switch 112553 1 or 2
2 4 Pin Connector 112738-4 1
3 Phone Jack 110386 2
4 Heat Sink, Driver Transistor 112733 8
5 Main Heat Sink 114276 2 1401
6 Screw, #4-40 x .25L Self Tap TORX 112650-04 8
6 Washer, Shoulder 113437 8
6 Insulator TO-220 112564 8
7 Ext. Tooth #6 Lock Washer 108261-06 2
8 LED Assembly Green 112614 1
9 Power Switch 112086 1 1401
10 Potentiometer 123408 1 1201
11 Front Panel 111997 1
12 Front Panel, Heatsink 118975 1 1401 II
13 1201 Heatsink 123120 1 1201
14 Screw, Hold Down 103140-04 2 1201
14 Nut, Hold Down 121710-04 2 1201
15 Transistor, Hold Down 123431 1 1201
16 Output, Harness Assy 123733 1 1201
16 Front Speaker Output Assy 121795 1 1401 II
16 Rear Speaker Output Assy 121796 1 1401 II
16 Power Cable Assy, Amp 119218 1 1401 II
17 Case, 1401 114521 1
17 Speaker, Output Assy 123731 1
18 Harness Assembly, Amp 112761 1 1401
19 Zinc Cover 114586 1
20 Knob 111994 2 or 3
21 1201 Cover 123381-1 1 1201
22 Support Bracket 112501 1
23 Angle Bracket 112502 2
23 AmpIifier Accy Kit, Mounting 119303 1
24 Input Wire Assembly 123750 1
25 Ground Wire Assembly 112760 1 1401
26 Power Wire Assembly 112579 1 1401
27 Power Cable (auto) 119215 1 1401 II
28 Front Speaker Cable Assy 121794 1 1401 II
28 Rear Speaker Cable Assy 119220 1 1401 II
--- Speaker Wiring Assy, Front and Rear 112745 1 1401
--- PC Mounting Strip 123465 1 1201
--- Screw, #6 Sheet Metal, Torx .5 Lg 107488-08 6
--- Screw, #4 Tap-Tite, Torx .5 Lg 122993-08 3
--- Transistor Insulator 122920 2
--- PC Insulator 123753 2 1201
--- Dust Cover 123858 2 1201
(Refer to Figures 3 and 4)
