ELECTRICAL PART LIST
1401 Series I
Reference Designator Description Part Number Note
R1 1K, 1/2W, 5%, CF 113777-102
R2, 3, 70, 90 150K, 2%, CF 107182-154 3
R4 10 Ohm, 5%, CF 103774-100
R10, 40, 77, 83 5.6K, 2%, CF 113773-562 3
R11, 21, 31, 41 910 Ohm, 5%, CF 107183-911
R12, 42 11K, 2%, CF 113773-113 3
R13, 43 220 Ohm, 5%, CF 113774-221
R14, 24, 34, 44, 86 47 Ohm, 5%, CF 107183-470
R15, 16, 25, 26, 36, 45, 46 27 Ohm, 5%, CF 113774-270 3
R16, 35, 45, 46 27 Ohm, 5%, CF 107183-270
R17, 18, 27, 28, 37, 38, 47,
48
.5 Ohm, 1.6W, 5%, WW 112737-OR5
R19, 22, 29, 32, 39, 49, 94,
159
18K, 2%, CF 107182-183 3
R19A,19B, 29A, 29B,
39A, 39B, 49A, 49B
4.7K, 5%, CF 113774-472 3
R20, 30 3K, 5%, CF 107183-302
R20, 30, 62, 71, 79, 87,
111, 114
3.3K, 2%, CF 107183-332 3
R23, 33 220 Ohm, 5%, CF 107183-221
R32 18K, 2%, CF 113773-183
R40, 69, 105 5.6K, 2%, CF 107182-562
R42 11K, 2%, CF 107182-113
R50 510 Ohm, 5%, CF 107183-511
R51, 53 47K, 5%, CF 107183-473
R52, 59, 71, 107 15K, 2%, CF 107182-153 3
R53, 60, 67, 73, 88, 99,
104, 110, 117-124
4.7K, 2%, CF 107182-472 3
R55 2 Ohm, 5%, CF 107183-2RO
R56, 62, 63, 75, 76, 87, 88,
91, 92, 93, 99, 100, 101,
102, 108, 111, 113, 114,
150
10K, 2%, CF 107182-103 3
R57, 58, 85, 155 24K, 5%, CF 107183-243 3
R52, 59, 61, 95, 96, 98,
104, 105
100K, 2%, CF 107182-104 3
R60, 68, 97 20 Ohm, 1W, 5%, CC
20 Ohm, 1W, 5%, CF (Alt)
104064-200
107163-200
3
R54, 61, 70, 84, 106 200K, 2%, CF 107182-204 3
R63, 67, 75, 76, 81, 82,
115, 116
6.8K, 2%, CF 107182-682 3
R64, 65, 90, 91, 98, 101,
103, 102
51K, 2%, CF 107182-513 3
R66, 89, 93, 100, 103 12K, 2%, CF 107182-123 3
R69, 89, 92, 151 62K, 2%, CF 107182-623 3
R72, 108, 109, 110 8.2K, 2%, CF 107182-822 3
R77, 78, 81, 112 2K, 2%, CF 107182-202 3
R78, 79, 82, 83, 113, 153 1.3K, 2%, CF 107182-132 3
R84, 157 1M, 5%, CF 113774-105 3
Resistors
