Bose COMPANION 20 User Manual

12
English
CONNECTING
Connecting the cables
Use the four provided cables and the AC power cord to make the
connections shown on page 13.
CAUTION: Do not plug in the AC power cord until all other connec-
tions are completed.
1. Insert one end of the audio in cable into the Audio In
connector on the back of the right speaker.
2. Insert the other end of the cable into the Headphone or
Speaker output connector (the labels and positions of these
connectors vary) on your computer.
3. Insert the control pod cable plug into the Control Pod
connector on the right speaker.
4. Insert the free end of the DC power cable into the DC
Power connector on the right speaker.
5. Insert the end of the left speaker cable into the Left
Speaker connector on the right speaker.
6. Insert the small end of the AC power cord into the power
pack and then insert the large end into an AC (mains) outlet.
a
b
c
d
e
Onyx.book Page 12 Tuesday, February 1, 2011 4:56 PM

Bose COMPANION 20 Specifications

General

Volume control	Rotary
Bass adjustment	Yes
Housing material	-
Recommended usage	PC
Speaker enclosure	Closed
Speaker placement	Tabletop/bookshelf
Audio output channels	2.0 channels
Frequency range	- Hz
RMS rated power	- W
Type	Bookshelf
Dimensions (WxDxH)	89 x 119 x 219 mm
Number of satellite speakers	2
Connector(s)	Audio In, 3.5mm
Headphone connectivity	3.5 mm
Connectivity technology	Wired
Power source type	AC
Cables included	AC, AUX
Package weight	2720 g

Weight and Dimensions

Depth	119 mm
Width	89 mm
Height	219 mm
Weight	1130 g
