Network Connection
The CSP-428 and CSP-1248 include a Network port on the rear panel
for network connection.
Use a foiled or unshielded twisted-pair (F/UTP) Cat 5e cable (not
included) to connect this port on each CSP to your network or
computer. Make this connection directly to the CSP or through a
switched Ethernet network.
Power Connection
The CSP-428 and CSP-1248 can operate with AC mains line voltages
from 85volts to 264 volts at 50 Hz/60 Hz over a detachable IEC
power cord. Power consumption is 37 volt-amps at an ambient
temperature of 40 °C (104 °F).
To power on the CSP, use the included power cord to connect the
processor's power inlet to a power outlet. After powering on, the boot
time may be as long as 40 seconds. The processor is fully operable
when the Power LED on the front panel is lit solid green.
Accessing the CSP Configuration Utility
To set the functions of the CSP, follow the steps below to access the
CSP configuration utility hosted on its integrated web server.
Note: The integrated web server is compatible only with Google
Chrome, Mozilla Firefox, Microsoft Edge, and Internet Explorer.
1. Visit bosepro.link/cspsw and download the Discovery Tool
application.
2. Connect your computer to the Network port of your CSP (see
Network Connection above).
3. Install and open the Discovery Tool application.
4. In the application, click Discover. The IP address of each CSP in the
network will appear in the window.
5. Enter the network address of the desired CSP into the address bar
of your web browser, and press Enter. The CSP configuration utility
will appear in the browser window.
To learn more, access the help system from within the interface of the
CSP configuration utility.
