Technical Specifications
Integrated DSP ESP-00 Series II
Signal Processor Four 32-bit floating-point digital signal processors, 200 MHz
Maximum Calculation 6.4 GIPS / 4.8 GFLOPS
Delay 288 s
Audio Latency 860 μs (analog in to analog out)
A/D and D/A Converters 24-bit
Sample Rate 48 kHz
Control Inputs
Inputs (Control) 8 analog or digital inputs, 5.1 kΩ internal pull-up resistor to 5 V, 3.81 mm Euroblock, 9-pin
Analog Input Voltage Range 0 V to 3.3 V (maximum 5 V)
Digital Input Voltage Range 0 V to 3.3 V (threshold voltage = 1.6 V)
Control Outputs
Outputs (Control) 8 digital outputs, 10 kΩΩ internal pull-up resistor to 5 V, 3.81 mm Euroblock, 9-pin
Output Voltage High: 5 V @ 0.5 mA
Low: < 1 V @ 10 mA, open collector
Indicators and Controls
LED Status Indicators Power, Status, Ethernet/Serial (RS-232 + CC-16)
Audio Signal Indication Green (-60 to -21 dBFS), Yellow (-20 to -7 dBFS), Red (-6 dBFS to Clip)
Electrical Specifications
Mains Voltage 85 VAC-264 VAC 50/60 Hz with PFC
AC Power Consumption < 35 VA typical / < 70 VA max at < 95°F (35 °C) ambient
Mains Connector IEC 60320-C14 (Inlet)
Power Dissipation 70 W (239 BTU, 60 kcal)
Physical
Dimensions 3.5" H x 19.0" W x 13.0" D (88 mm x 483 mm x 331 mm)
Net Weight 10.8 lb (4.9 kg)
Operating Temperature 32 °F - 104 °F (0 °C - 40 °C)
Cooling System Internal fan
General
PC Configuration Software ControlSpace
®
Designer
™
software
Network Control Ethernet (RJ-45), 10Base-T
Communication Ports RS-232 (DB9M, DTE), Bose CC-16 (5.08 mm Euroblock 3-pin)
Expansion Slots 8 analog/digital audio, 2 GPIO (1 occupied)
Audio Channel Capacity 64 (bi-directional, digital and/or analog)
