Bose F1 812 User Manual

English - 21
Care and Maintenance
Technical Information
Physical
Dimensions Weight
F1 Model 812 Loudspeaker 26.1" H x 13.1" W x 14.6" D (665 mm H x 334 mm W x 373 mm D) 44.5 lb (20.18 Kg)
F1 Subwoofer 27.0" H x 16.1" W x 17.6" D (688 mm H x 410 mm W x 449 mm D) 55.0 lb (24.95 Kg)
F1 system stack 73.5" H x 16.1" W x 17.6" D (1868 mm H x 410 mm W x 449 mm D) 99.5 lb (45.13 Kg)
Electrical
AC power rating Peak inrush current
F1 Model 812 Loudspeaker
100–240V
2.3–1.2A 50/60Hz
120 V RMS: 6.3A RMS
23 V RMS: 4.6A RMS
F1 Subwoofer
100–240V
2.3–1.2A 50/60Hz
120 V RMS: 6.3A RMS
23 V RMS: 4.6A RMS
Input/Output Connector Wiring Reference
TRS balanced TS unbalanced
XLR balanced
1 – Shield (ground)
3 – Minus (–)
2 – Plus (+)
XLR unbalanced
1 – Shield (ground)
3 – Minus (–)
2 – Plus (+)
