English - 9
Installation
Technical Specifications
System Performance
Frequency Range (–10 dB)
50 Hz – 16 kHz
Coverage Pattern, Horizontal 120°
Coverage Pattern, Vertical 100°
Long-Term Power Handling
(1)
300 W
Calculated Maximum SPL @ 1 m, peak
(2)
123 dB
Requires active EQ for best performance Yes
Transducers
Driver Compliment Eight (8) 4.5" (114 mm) full-range environmental drivers
Nominal Impedance 8 ohms
Physical
Dimensions 13.3" H x 20.5" W x 12.9" D (338 mm x 520 mm x 327 mm)
Net Weight 37 lb (16.8 kg)
Finish Color Black
Environmental Rating Outdoor (IP55)
Suspension / Mounting Eight (8) M8 x 1.25 inserts (2 back, 2 bottom)
Shipping Weight 42 lb (19.1 kg)
Product Code
Black 739058-0110
Notes:
1. Power handling using Bose Extended-Lifecycle Test.
2. Maximum SPL calculated from sensitivity and power handling specifications, exclusive of power compression.
3. All specifications subject to change without notice.
