Bose S1 PRO+ User Manual

CHANNEL AND SYSTEM SETTINGS
34
|
ENG
SUB EQ SETTINGS
The Sub EQ setting is a crossover that optimizes system EQ for setup scenarios in
which a powered subwoofer is connected to the system LINE OUT port.
You can use Sub EQ with any powered subwoofer, but for optimal performance, Bose
recommends the Bose Sub1 or Sub2 Powered Bass Module.
Once you enable Sub EQ, it stays enabled until you disable it or the system powers o.
For sample setup scenario images, see page 52.
NOTES:
• For information on how to connect the system to a Bose Sub1 or Sub2 Powered
Bass Module, refer to the Bose Sub1/Sub2 Powered Bass Module owner’s guide.
Visit: support.Bose.com/Sub1support.Bose.com/Sub1 or support.Bose.com/Sub2support.Bose.com/Sub2
• You can also enable/disable Sub EQ using the Bose Music app. You can access this
option from the Settings menu.
Enable/Disable Sub EQ
1. Press and hold the channel control for Channel 3 until the additional controls menu
appears on the channel display.
Press + Hold
to access
additional
product
controls
Auto O
Live Stream
Sub EQ
Expanders
O
On
O
On

Bose S1 PRO+ Specifications

General

Type	Handheld Public Address (PA) system
Handle(s)	Yes
Product color	Black
Housing material	Aluminium, Polypropylene (PP)
Storage temperature (T-T)	-20 - 49 °C
Operating temperature (T-T)	0 - 45 °C
Bluetooth range	9 m
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	2
Charging time	5 h
AC input voltage	100 - 240 V
Battery capacity	5500 mAh
Power source type	AC, Battery
AC input frequency	50/60 Hz
Battery life (max)	11 h
Number of mixer channels	3 channels
Speaker type	2-way
Number of speakers	-
Frequency range	- Hz
RMS rated power	- W

Weight and Dimensions

Depth	279.8 mm
Width	240 mm
Height	332.6 mm
Weight	6500 g
