Bose S1 PRO+ User Manual

SYSTEM STATUS
59
|
ENG
CHANNEL DISPLAYS
Shows the status and settings of each channel, the system, and any connected
wireless transmitters.
How to read the channel displays
VOLUME
Channel Mute
Status and battery icons
Selected
channel
parameter
Channel
parameter
level
Channel or
system status
messages
Status icons
The status icons show channel and system settings.
ICON MEANING
The default Instrument ToneMatch preset is applied to the channel.
A custom Instrument ToneMatch preset is applied to the channel.
The default Microphone ToneMatch preset is applied to the channel.
A custom Microphone ToneMatch preset is applied to the channel.
Live Stream mode is enabled.
A wireless transmitter is connected to the channel.
NOTE: If the transmitter is a Bose Wireless Mic/Line Transmitter, this icon
indicates that the transmitter input setting is set to mic input.
LINE
A Bose Wireless Mic/Line Transmitter is connected to the channel, and the
transmitter input setting is set to line input.

Bose S1 PRO+ Specifications

General

Type	Handheld Public Address (PA) system
Handle(s)	Yes
Product color	Black
Housing material	Aluminium, Polypropylene (PP)
Storage temperature (T-T)	-20 - 49 °C
Operating temperature (T-T)	0 - 45 °C
Bluetooth range	9 m
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	2
Charging time	5 h
AC input voltage	100 - 240 V
Battery capacity	5500 mAh
Power source type	AC, Battery
AC input frequency	50/60 Hz
Battery life (max)	11 h
Number of mixer channels	3 channels
Speaker type	2-way
Number of speakers	-
Frequency range	- Hz
RMS rated power	- W

Weight and Dimensions

Depth	279.8 mm
Width	240 mm
Height	332.6 mm
Weight	6500 g
