Page 3
Switch and Sensor Locations
Threshold Strip Switch
31221A (Qty. 2)
*Bridging
Microswitch
31010RA
(Rear Pump)
31010FA (Front Pump)
*Note: Mirror image for
right (front) pump lifts.
Inboard
Outboard
Right
Left
*IB Occupancy
Microswitch Assy.
31643A
*Rotary
Position
Sensor
31194A
*Stow Microswitch
23184 (Qty. 2)
*Ground Detect
Magnetic Sensor
30433A60
*Outboard Barrier
Link / Slide Magnet Assy.
985-0201NA
*Outboard Barrier Raised
Magnetic Sensor
30433A60
UP
D
OWN
3
2
8
1
9
F
O
L
D
U
N
FO
L
D
3
2
8
2
0
®
*Pin - Platform
Slide / Magnet Assy.
33182A
