Page 31
Exploded Views and Parts Lists
NCL917IB-2 & NCL917FIB-2 Platform Assembly
BEARING-FLANGE-1 X 1/2-16FDU08
4
28031
12
RING-3/8 RETAINING SNAP
13889
2
9
PLATFORM-NCL917IB-2 33" X 51"1 1 945-23351NW
ROLL STOP-ALUM/RUBBER END/ASSY/33"12 945-3312NA33Y
STOP-PLATFORM23 900-0311
BKT-LATCH/ROLL STOP/REAR
1
6
945-3202RN
ROLL STOP ACTIVATION FOOT
1
7
945-0200NW-33
4
81003-000
2
SCREW-5/16-18 X 1-1/4 SHCS BK ZINC
990-0341
22
2
ADAPT-CYL/ROLL STOP LEVER-OUT
4
8
29371
WASHER-THRUST-.875 OD/.50 ID/.0585T
19
2
24932BK
PIN-CLEVIS 3/8 X 3" EFF LEN.-W/O HOLE/BK
21
4
24537
SCREW-#10-32X3/8 FL HD-HX SKT/AUTO-BK
26
2 945-2336N BEARING-PLATFORM SLIDE
1
5
945-3202FN
BKT-LATCH/ROLL STOP/FRONT
10
ASSY-ROLL STOP LATCH/OCCUPIED SWITCH
1
945-4206RNA
11
LATCH-ROLL STOP/FRONT1
945-4206FN
13
BEARING-PLASTIC-FLANGE-3/8IDX1/4"
6
24028
14
STANDOFF-FOOT MOUNT2
32759
15
SCREW-10-32 X 1.25" SHCS
2
40-1092-0
16
BOLT-5/16-18 X 1" HEX HD. CAP
2
10013
17
NUT-5/16-18 HEX/AUTO-BK
2
10058
18
BRACKET ADJUST-SPLIT FOOT
2
33411
27
4
15733
BOLT-1/4-20X1/2" BUT HD SOC/AUTO-BK
28
2 32831
GAS-SPRING-30LB-3.54X9.65
20
2
36003
HAIRPIN COTTER-STAINLESS-.042"
29
1
915-0147NWY
WMT-BRIDGE PLATE-PLT-33/48" FTG (945-0147NAY INCL. 29, 36-47)
30
2
28324BK
NUT-5/16-18 TOP LOCK/AUTO-BK
CABLE TIE 3 3/4" BLACK
4
31
91010-000 *
DECAL-BOUNDARY YELLOW LEXAN 1" X 35 1/2"
2
32
30236R035.5
10775
4
NUT-1/4-20 HEX LOCK/AUTO-BK
18663
2
23
25
SCREW-1/2-20 X 1.5 SET-LOCK/AUTO-BK
40-4230-0
24
4
SCREW-1/4-20 X 5/8" FHSC
PART NO .QTY.ITEM DESCRIPTION
* ITEMS NOT SHOWN
DECAL-BOUNDARY YELLOW LEXAN 1" X 32 1/2"
1
33
30236R032.5
PIN-ROLLSTOP GAS SPRING
2
34
34686
DECAL-BOUNDARY YELLOW LEXAN 1" X 11"
2
35
30236R011
BOLT-3/8-16 x 3/4" FLBHSCS-GD8
4
36
25171
BEARING-FLANGE-3/4" X 1/4"-12FDU04
2
37
24012
NUT-1/4-20 HEX
2
38
10057
WASHER-1/4 EXT STAR TOOTH LOCK ZP
2
39
83588
RUBBER BUMPER-VERT CHAN.
1
40
32408
NUT-3/8-16 HEX/AUTO-BK
4
41
10059BK
BUMPER-1" X 5/8" LG NAT UHMW/BRIDGEPLATE
2
42
33603
BOLT-1/4-20 X 1" HEX
2
43
10001
WMT-BKT-BRIDGE PLATE/RR
1
44
945-0431RNW
BEARING-UHMW FLAT-THIN-BLK
3
45
916-5406
WMT-BKT-BRIDGE PLATE/FR
1
46
945-0431FNW
WASHER-3/8" LOCK/AUTO-BK
4
47
10069BK
PART NO .QTY.ITEM DESCRIPTION
3
29
36
45
45
43
47
41
42
46
39
38
37
44
43
42
41
47
40
39
38
37
23
30
12
12
30
23
12
27
28
24
7
34
14
13
19
20
25
10
13
15
16
17
18
2
5
6
26
8
9
3
4
1
11
4
12
21
21
22
8
1
NOTE:
1
NOTE:
1
NOTE:
2
NOTE:
33
32
35
3
NOTE:
4
NOTE:
45
DWG. NOTES
1) USE LOCTITE
®
THREADLOCKER RED 271™ OR EQUIVALENT ON SCREWS (B.C. #24537 AND B.C. 15733
2) USE LOCTITE
®
THREADLOCKER GREEN 290™ OR EQUIVALENT ON CLEVIS PINS (B.C. #24932BK)
3) APPLY BOUNDARY DECAL (ITEM 33) 48 1/8" FROM FRONT EDGE OF PLATFORM TO LEADING EDGE OF DECAL.
4) INBOARD EDGE OF DECAL (ITEM 32) TO BEGIN AT 48 1/2"
36
