Brother FS-40 User Manual

2 - 3
Main parts
Basics of Disassembly
Basics
1 Removal of Accessory table
1. Remove the accessory table 1.
1
2 Removal of Needle plate B assy
1. Slide the slide button B 1, and then remove the needle plate B assy. 2.
→ Refer to 3 - 3 "Disassembly of Needle plate B assy".
2
1
3 Removal of Base cover
1. Remove the 4 screws 1, and then remove the base cover 1.
1
1

Brother FS-40 Specifications

General

Stitch Number	40
Buttonhole Styles	5
Display	LCD
Lighting	LED
Type	Electronic
Needle Threading	Automatic
Adjustable Stitch Length	Yes
Adjustable Stitch Width	Yes
Maximum Stitch Width	5 mm
Maximum Stitch Length	4 mm
Reverse Sewing	Yes
Free Arm	Yes
Start/Stop Button	Yes
Speed Control	Yes
Bobbin	Top-loading
Sewing Speed	750 stitches per minute
