Brother GTX User Manual

days
7
!
OKOK
MENUMENU
To achieve a good weekly maintenance you will have to do the following actions:
WEEKLY MAINTENANCE PROCEDURES
The black silicon lips of the two suction caps should be cleaned using the Cleaning
Stick T dipped in Cleaning Solution. Carefully remove any build-up of dried ink sitting
on the lips of the suction caps. This will prevent air leaks and keep the good suction of
the pumps.
Be careful not to touch the foam - keep it at.
TO BE DONE EVERY WEEK
Suction Cap & Exhaust Cleaning
Exhaust Cleaning
Extrusion lances
Direction to cleanSuction Cap Cleaning
Always use this menu to perform cleanings or replace parts:
+ Nozzle Guards Cleaning
+ Exhaust Cleaning
+ Wiper Cleaning
+ Suction Cap Cleaning
WEEKLY MAINTENANCE
WEEKLY MAINTENANCE
The four extrusion lances (see in the blue circle…) and the
hole sitting on the side of the capping at the Exhaust position
also need to be cleaned and free of dried ink.
Always clean the Exhaust hole rst, then proceed backward to
clean the lances.
Menu > Maintenance > Maintenance Part Clean/Replace > and follow instructions on the display
15
Min
Watch the Video: Cleaning the Nozzle Guard, Wiper Blade,
Suction and Exhaust Caps
9
