Replacing the Presser Foot 43
1
—
— — — — — — — — — — — — — — — — — — —
—
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Removing the presser foot
holder
Remove the presser foot holder when cleaning the
sewing machine or when installing a presser foot that
does not use the presser foot holder, such as the
quilting foot. Use the screwdriver to remove the
presser foot holder.
■ Removing the presser foot holder
a
Remove the presser foot.
• For details, refer to “Replacing the presser
foot” (page 41).
b
Use the screwdriver to loosen the presser foot
holder screw.
a Screwdriver
b Presser foot holder
c Presser foot holder screw
■ Attaching the presser foot holder
a
Align the presser foot holder with the lower-
left side of the presser bar.
a Presser bar
b Presser foot holder
b
Hold the presser foot holder in place with your
right hand, and then tighten the screw using
the screwdriver in your left hand.
a Screwdriver
Note
z If the presser foot holder is not correctly
installed, the thread tension will be incorrect.
a
b
c
a
b
a
