Brother MFC-5890CN User Manual

Chapter 8
86
f If you want to change the first Fax/Tel
number, press a or b to choose
Fax/Tel:, then press
c and enter the
new fax or telephone number using the
dial pad (up to 20 digits).
Press OK.
Note
For Speed Dial locations you can change
Fax/Tel1: and Fax/Tel2:.
g Do one of the following:
 If you are changing a Speed Dial
number, go to step h.
 If you are changing a One Touch
number, go to step i.
h Do one of the following:
 Enter the second new fax or
telephone number (up to 20 digits).
Press OK.
 If you do not want to change the
second number, press OK.
i Press a or b to choose Complete.
Press OK.
j Press Stop/Exit.
Setting up groups for
broadcasting 8
Groups, which can be stored on a One Touch
key or a Speed Dial location, allow you to
send the same fax message to many fax
numbers by pressing only a One Touch key
or (Phone Book), Search, OK, the two-
digit location and Black Start. First, you'll
need to store each fax number in a
One Touch key or Speed-Dial location. Then
you can include them as numbers in the
Group. Each Group uses up a One Touch
key or Speed Dial location. You can have up
to six Groups, or you can assign up to
164 (MFC-5890CN and MFC-5895CW),
204 (MFC-6490CW) numbers in a large
Group.
(See Storing Speed Dial numbers
on page 83 and Broadcasting (Black & White
only) on page 43.)
a Press (Phone Book).
b Press a or b to choose Setup Groups.
Press OK.
c Press a or b to choose GROUP1,
GROUP2, GROUP3, GROUP4, GROUP5 or
GROUP6 for the Group name where you
will store the fax numbers.
Press OK.
d Press a or b to choose the 2-digit One
Touch or Speed Dial location where you
want to store the Group.
Press OK.
e If you want to change the Group name,
press a or b to choose
Change Group Name and press OK.
Then enter the new Group name and
press OK.
f Press a or b to choose Add Number.
Press OK.

Brother MFC-5890CN Specifications

General

Duplex printing	No
Print technology	Inkjet
Maximum resolution	1200 x 6000 DPI
Print speed (black, normal quality, A4/US Letter)	35 ppm
Print speed (color, normal quality, A4/US Letter)	28 ppm
Scan to	E-mail, File, Image, OCR, USB
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Maximum scan area	216 x 356 mm
Output color depth	24 bit
Scan speed (black)	3.44 ppm
Image formats supported	BMP, JPG
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Copier resize	25 - 400 %
PC free copying	Yes
Maximum copy resolution	1200 x 1200 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
Copy speed (black, normal quality, A4)	23 cpm
Copy speed (color, normal quality, A4)	20 cpm
Faxing	Color faxing
Fax memory	400 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	80
Total input capacity	150 sheets
Total output capacity	50 sheets
Processor family	RISC
Compatible memory cards	CF, Memory Stick (MS), miniSD, MS PRO, MS Pro, SD, SDHC, xD
Sound pressure level (printing)	50 dB
Display	LCD
Display diagonal	3.3 \
Market positioning	Home & office
Maximum print size	297 x 432 mm
Paper tray media types	Glossy paper, Photo paper, Plain paper
Paper tray media weight	64 - 220 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
JIS B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Dimensions (WxDxH)	485 x 408 x 242 mm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	copy, fax, print, scan
AC input frequency	50 - 60 Hz
Power consumption (standby)	6 W
Power consumption (PowerSave)	4.5 W
Power consumption (average operating)	27 W
Maximum duty cycle	- pages per month
Sustainability certificates	ENERGY STAR
Mac operating systems supported	Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
