Brother MFC-8860DN Service Manual

8-25 Confidential
USB USB Serial No.
DRUM Drum counter
COVERAGE
*3
Average black coverage
TTL_PG Total number of pages printed
COPY Number of copies made
PC PRINT Number of PC prints made
FAX/LIST
*1
Number of FAX outputs made
TR1_PG Number of pages picked up from the paper tray1
TR2_PG Number of pages picked up from the paper tray2
MP_PG Number of pages picked up from the MP tray
DX_PG
*2
Number of pages picked up from the DX tray
A4+LTR Number of A4/Letter size sheets picked up
LG+A4L Number of Legal/A4-Long size sheets picked up
B5+EXE Number of B5/Executive size sheets picked up
ENVLOP Number of envelopes picked up
A5 Number of A5 size sheets picked up
OTHER Number of other-size sheets picked up
TTL_JAM Total number of jams
TR1_JAM Number of jams that occurred at the paper tray1
TR2_JAM Number of jams that occurred at the paper tray2
MP_JAM Number of jams that occurred at the MP tray
DX_JAM
*2
Number of jams that occurred at the DX tray
IN_JAM Number of jams that occurred at the feeding
RE_JAM Number of jams that occurred at the ejecting
DRUM_CH Number of times the drum has been replaced
DRUM_PG Number of pages printed by a drum
TNER_CH Number of times the toner cartridge has been replaced
TNER_PG1 Number of pages printed with the current toner cartridge
TNER_PG2 Number of pages printed with the previous toner cartridge
DEV_BIAS Current bias voltage
MACHINE ERR_01 to 10 Last machine error code 01 to 10
ADF_JAM
*2
Number of document jams that occurred at the ADF
ADF_PG
*2
Number of scanned pages from the ADF
FB_PG Number of scanned pages from the FB
COMERR1 to 3 Last communication error code 1 to 3
*1: For MFC-8460N/8860DN/8870DW, “FAX” is displayed. For DCP-8060/8065DN, “LIST” is
displayed.
*2: For MFC-8460N and DCP-8060, “LIST” is displayed, but number of pages or jams is not
counted.
*3: Some margin of error must be taken into consideration because coverage for the printable area
of A4-size paper is calculated using video signals.

Brother MFC-8860DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Grayscale levels	256
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
Paper tray media types	Envelopes, Plain paper, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows98(SE)/Me/2000/XP/NT4.0WS Mac OS 9.1-9.2/ OS X 10.2.4 +
Standard interfaces	USB 2.0
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	1104 W
Sustainability certificates	ENERGY STAR
