Lerchenfeldstr. 9
87600 Kaufbeuren
Tel.: +49 (0)8341 9764-0 Fax: +49 (0)8341 67806
14
Technical data
Power supply: Direct current 12 V
Implementation: According to Association of German Electrotechnical
Engineers regulations and the provisions of the
Instrument Safety Act.
Test labelling:
Use: For use in caravan in connection with MES Module A
and B
Front plate: Aluminium plain anodised / printed
Height: 93 mm Width: 88 mm Weight: 70 g (0.7 N)
Assembly
Remove the items packed separately (accessories) from the main carton, and
check them for completeness.
2 Fastening screws
1 Serial RS485 data transmission cable (4-pole)
1 Operating instructions
Put the control panel onto a part of the caravan that is protected from moisture.
The opening for installing the control panel must be of a breadth of approx. 69
mm and a height of approx. 60 mm.
