imagePROGRAF TM-Series Service Guide June 2021
Revision 4 Page 29
K. Consumable Parts
Consumable parts are parts having a limited life that will be reached during a
customer’s specific machine operation, and should then be replaced as
needed. Examples of consumable parts include, but are not limited to, the linear
scale and carriage unit.
An estimated consumable parts list is available in the tables below to assist in
the initial parts/supplies planning. A consumable part’s life expectancy is
directly related to the printer usage factors such as paper size, paper quality,
environment, usage application, and machine maintenance. Therefore,
consumable parts do not have a warranty, and Canon USA cannot guarantee
a minimum life.
Note: All consumable parts shown in the table below are for reference
purposes only, and are subject to change without notice.
Table 27 - imagePROGRAF TM-305 / TM-300 Consumable Parts List
Unit Description
Counter
Name
Part Number
2
Estimated Life
15
(A0 Size)
Carriage
Carriage unit CR1 QM4-6732-000
16,000 sheets
Carriage unit
CR2
QM4-6732-000
Timing slit strip film
QC4-8815-000
Carriage unit
CR3
QM4-6732-000
87,000 sheets
Ink supply
Ink tube unit
CR4
QM4-5963-000
28,000 sheets
Multi sensor
Multi sensor unit
CR5
QM4-5977-000
16,000 sheets
Purge Purge unit
PG1
QM4-6171-000 50,000 sheets
PG2
PG3
Non-ejection
detection
Head management sensor unit Hma1 QM4-6180-000 60,000 sheets
Carriage motor DC motor MT1 QK2-5068-000 200,000 sheets
LF encoder
sensor
Paper feed encoder unit
LFS1
QM4-6205-000
25,000 sheets
Film, timing slit disk
QD1-2702-000
Mist collection
Exhaust mist duct unit
Mi1
QM4-5995-000
30,000 sheets
Waste ink
Waste ink box unit, HP
Wia1
QM4-5984-000
14,000 sheets
Waste ink box unit, BP
Wia2
QM4-5986-000
Waste ink box unit, Center Wia5 QM4-5985-000
Platen fan unit
Wia7
QM4-5987-000
103,000 sheets
2 Part numbers are subject to change without notice.
15
Based on Heavyweight Coated Paper HG 145 g/m
2
, Photo illustration, standard mode, Image Duty: 12.5% × 3 color (CMY) +
6.8% (MBK) + 5.7% (BK) = 50% Duty. The estimated life is subject to change depending upon many factors including, without
limitation the print mode, operating condition, type of image printed and customer handling of the equipment.
