Canon PIXMA MX310 Service Manual

2. ADJUSTMENT / SETTINGS
2-1. Service Mode
<Service mode operation procedures>
1) With the machine power turned off, while pressing the Stop/Reset button, press and hold the ON/OFF
button. (DO NOT release the buttons). The Power LED lights in green to indicate that a function is
selectable.
2) While holding the ON/OFF button, release the Stop/Reset button. (DO NOT release the ON/OFF button.)
3) While holding the ON/OFF button, press the Stop/Reset button 2 times, and then release both the
ON/OFF and Stop/Reset buttons. (Each time the Stop/Reset button is pressed, the Alarm and Power
LEDs light alternately, Alarm in orange and Power in green, starting with Alarm LED.)
4) When the Power LED lights in green (and "Service Mode Idle" is displayed on the LCD), press the
Stop/Reset button the specified number of time(s) according to the function listed in the table below,
then press the ON/OFF button. (Each time the Stop/Reset button is pressed, the Alarm and Power LEDs
light alternately, Alarm in orange and Power in green, starting with Alarm LED.)
Time(s) LED indication Function Remarks
0 times Green (Power) Power off When the ink cartridge is not installed, the
carriage returns and locks in the home position
capped.
1 time Orange (Alarm) Service test print Service test print
- Model name
- ROM version
- Ink absorber counter value (ink amount in the
ink absorber)
- USB serial number
- Destination
- EEPROM information
- Barcode (model name + destination), etc.
2 times Green (Power) EEPROM information
print
EEPROM information print
- Model name
- Destination
- ROM version
- Ink absorber counter value (ink amount in the
ink absorber)
- Print information
- Error information, etc.
3 times Orange (Alarm) EEPROM initialization The following items are NOT initialized, and the
shipment arrival flag is not set:
- Destination settings
- Absorbed ink amount
- USB serial number
- Region code of ink cartridge
- Record of ink absorber counter resetting and
setting, etc.
(11/32)

Canon PIXMA MX310 Specifications

General

DVD/CD printing	No
Print technology	Inkjet
Maximum resolution	4800 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)	22 ppm
Print speed (color, normal quality, A4/US Letter)	17 ppm
Number of print cartridges	4
Scanner type	Flatbed scanner
Input color depth	48 bit
Maximum scan area	216 x 297 mm
Optical scanning resolution	1200 x 2400 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	22 cpm
Copy speed (color, normal quality, A4)	17 cpm
Faxing	Color faxing
Fax coding methods	MH, MR
Error Correction Mode (ECM)	Yes
Maximum input capacity	100 sheets
Auto document feeder (ADF) input capacity	30 sheets
Envelopes sizes	DL
Media weight (tray 1)	64 - 105 g/m²
Paper tray media types	Envelopes, Glossy paper, Photo paper, Plain paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Borderless printing media sizes	A4
Minimum system requirements	CD-ROM / 1024x768
Sound pressure level (printing)	40 dB
Dimensions (WxDxH)	465 x 440 x 230 mm
Power requirements	AC 100-240V, 50/60Hz
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	copy, fax, print
Compatible operating systems	Windows Vista / Windows XP SP1, SP2 / Windows 2000 Professional SP2, SP3, SP4 Mac OS X v.10.2.8 - v.10.4
Minimum RAM	128 MB
Minimum processor	Pentium II 300 MHz/PowerPC G3
Minimum storage drive space	800 MB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (off)	1.1 W
Power consumption (standby)	1.8 W
Power consumption (average operating)	16 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Market positioning	Home & office
