Canon PowerShot SX260 HS User Manual

Initial Preparations
15
Charge the battery.
z For CB-2LY: Flip out the plug ( ) and plug
the charger into a power outlet ( ).
z For CB-2LYE: Plug the power cord into the
charger, then plug the other end into a power
outlet.
X The charging lamp turns orange and
charging begins.
X When the charging is finished, the lamp turns
green.
Remove the battery.
z After unplugging the battery charger, remove
the battery by pushing it in ( ) and up ( ).
Insert the included battery and a memory card (sold separately).
Note that before using a new memory card (or a memory card formatted in
another device), you should format the memory card with this camera (p. 185).
Check the card’s write-protect tab.
z Recording is not possible on memory cards
with a write-protect tab when the tab is in the
locked (downward) position. Slide the tab up
until it clicks into the unlocked position.
CB-2LY
CB-2LYE
• To protect the battery and keep it in optimal condition, do not charge
it continuously for more than 24 hours.
• For battery chargers that use a power cord, do not attach the charger
or cord to other objects. Doing so could result in malfunction or
damage to the product.
• For details on charging time and the number of shots and recording time
possible with a fully charged battery, see “Specifications” in the Getting Started
guide.
Inserting the Battery and Memory Card
COPY

Canon PowerShot SX260 HS Specifications

General

Megapixel	12.1 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Image sensor size	1/2.3 \
Image formats supported	JPEG XR
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4000 x 3000 pixels
Still image resolution(s)	480 x 480, 640 x 360, 640 x 424, 640 x 480, 1200 x 1200, 1600 x 1064, 1600 x 1200, 1920 x 1280, 2112 x 2112, 2816 x 1584, 2816 x 1880, 2816 x 2112, 2992 x 2992, 4000 x 2248, 4000 x 2664, 4000 x 3000
Digital zoom	4 x
Optical zoom	20 x
Combined zoom	80 x
Focal length range	4.5 - 90 mm
Minimum aperture number	-
Maximum focal length (35mm film equiv)	500 mm
Minimum focal length (35mm film equiv)	20 mm
Focus	TTL
Focus adjustment	Auto/Manual
Normal focusing range	0.05 - ∞/1 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Macro focusing range (wide)	0.05 - 0.5 m
Normal focusing range (tele)	1 - ∞ m
Normal focusing range (wide)	0.05 - ∞ m
ISO sensitivity	100, 200, 400, 800, 1600, 3200, Auto
ISO sensitivity (max)	3200
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 2EV (1/2EV step)
Fastest camera shutter speed	1/3200 s
Slowest camera shutter speed	15 s
Flash modes	Auto, Flash off, Flash on, Manual, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 2 m
Flash range (wide)	0.5 - 3.5 m
Power source type	Battery
Video resolutions	320 x 240, 640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	24 fps
Video formats supported	H.264, MOV
Maximum video resolution	1920 x 1080 pixels
Memory slots	1
Internal memory	- MB
Compatible memory cards	MicroDrive, MicroSD (TransFlash), MicroSDHC
Display diagonal	3 \
Display resolution (numeric)	461000 pixels
USB version	2.0
USB connector	Mini-USB B
Photo effects	Black&White, Neutral, Sepia
White balance	Auto, Cloudy, Custom modes, Daylight, Fluorescent, Fluorescent H, Tungsten
Self-timer delay	2, 10 s
Battery type	NB-6L
Battery voltage	3.4 V
Battery capacity	1000 mAh
Battery life (CIPA standard)	230 shots
Product color	Red
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	32.7 mm
Width	106.3 mm
Height	61 mm
Weight	208 g
Weight (including battery)	231 g
