Canon PowerShot SX260 HS User Manual

Using Optional Accessories
201
Display images.
z Follow steps 3 – 4 on p. 199 to display
images.
Connecting the camera to an HDMI CEC-compatible TV enables playback
(including slideshow playback) using the TV remote control.
In this case, you will need to adjust some TV settings. For details, refer to the
TV user manual.
Configure the setting.
z Press the n button, choose [Ctrl via
HDMI] on the 3 tab, and then choose [Enable]
(p. 40).
Connect the camera to the TV.
z Follow steps 1 – 2 on p. 200 to connect the
camera to the TV.
Display images.
z Turn on the TV. On the camera, press the 1
button.
X Images from the camera are now displayed
on the TV. (Nothing is displayed on the
camera screen.)
• It is not possible to connect the included interface cable or an optional
stereo AV cable at the same time as an HDMI Cable HTC-100.
Forcing the cables into the camera at the same time may damage the
camera or cables.
• Camera operating sounds are not played while the camera is connected to an
HDTV.
Controlling the Camera with a TV Remote
SX260 HS
SX240 HS
COPY

Canon PowerShot SX260 HS Specifications

General

Megapixel	12.1 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Image sensor size	1/2.3 \
Image formats supported	JPEG XR
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4000 x 3000 pixels
Still image resolution(s)	480 x 480, 640 x 360, 640 x 424, 640 x 480, 1200 x 1200, 1600 x 1064, 1600 x 1200, 1920 x 1280, 2112 x 2112, 2816 x 1584, 2816 x 1880, 2816 x 2112, 2992 x 2992, 4000 x 2248, 4000 x 2664, 4000 x 3000
Digital zoom	4 x
Optical zoom	20 x
Combined zoom	80 x
Focal length range	4.5 - 90 mm
Minimum aperture number	-
Maximum focal length (35mm film equiv)	500 mm
Minimum focal length (35mm film equiv)	20 mm
Focus	TTL
Focus adjustment	Auto/Manual
Normal focusing range	0.05 - ∞/1 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Macro focusing range (wide)	0.05 - 0.5 m
Normal focusing range (tele)	1 - ∞ m
Normal focusing range (wide)	0.05 - ∞ m
ISO sensitivity	100, 200, 400, 800, 1600, 3200, Auto
ISO sensitivity (max)	3200
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 2EV (1/2EV step)
Fastest camera shutter speed	1/3200 s
Slowest camera shutter speed	15 s
Flash modes	Auto, Flash off, Flash on, Manual, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 2 m
Flash range (wide)	0.5 - 3.5 m
Power source type	Battery
Video resolutions	320 x 240, 640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	24 fps
Video formats supported	H.264, MOV
Maximum video resolution	1920 x 1080 pixels
Memory slots	1
Internal memory	- MB
Compatible memory cards	MicroDrive, MicroSD (TransFlash), MicroSDHC
Display diagonal	3 \
Display resolution (numeric)	461000 pixels
USB version	2.0
USB connector	Mini-USB B
Photo effects	Black&White, Neutral, Sepia
White balance	Auto, Cloudy, Custom modes, Daylight, Fluorescent, Fluorescent H, Tungsten
Self-timer delay	2, 10 s
Battery type	NB-6L
Battery voltage	3.4 V
Battery capacity	1000 mAh
Battery life (CIPA standard)	230 shots
Product color	Red
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	32.7 mm
Width	106.3 mm
Height	61 mm
Weight	208 g
Weight (including battery)	231 g
