Initial Preparations
Prepare for shooting as follows.
Attaching the Strap
 Thread the end of the strap through the
strap hole (
), and then pull the other
end of the strap through the loop on the
threaded end (
).
Holding the Camera
 Place the strap around your wrist.
 When shooting, keep your arms close to
your body and hold the camera securely
to prevent it from moving. If you have
raised the ash, do not rest your ngers
on it.
Charging the Battery Pack
Before use, charge the battery pack with the included charger. Be sure to
charge the battery pack initially, because the camera is not sold with the
battery pack charged.
1 Insert the battery pack.
 After aligning the  marks on the battery
pack and charger, insert the battery pack
by pushing it in (
) and down ( ).
2 Charge the battery pack.
 CB-2LY: Flip out the plug ( ) and plug
the charger into a power outlet (
).
 CB-2LYE: Plug the power cord into the
charger, then plug the other end into a
power outlet.
 The charging lamp turns orange, and
charging begins.
 When charging is nished, the lamp turns
green.
CB-2LY
CB-2LYE
COPY

Canon PowerShot SX700 HS Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Image sensor size	1/2.3 \
Image formats supported	JPG
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	4608 x 3456, 3264 x 2448, 2048 x 1536, 640 x 480, \\r 4608 x 2592, 3264 x 1832, 1920 x 1080, 640 x 360, \\r 4608 x 3072, 3264 x 2176, 2048 x 1368, 640 x 424, \\r 3456 x 3456, 2448 x 2448, 1536 x 1536, 480 x 480
Digital zoom	4 x
Optical zoom	30 x
Combined zoom	120 x
Focal length range	4.5 - 135 mm
Maximum aperture number	6.9
Minimum aperture number	3.2
Lens structure (elements/groups)	13/10
Maximum focal length (35mm film equiv)	750 mm
Minimum focal length (35mm film equiv)	25 mm
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	9
Auto focusing (AF) modes	Continuous Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance	0.01 m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	3200
ISO sensitivity (min)	100
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/3200 s
Slowest camera shutter speed	15 s
Flash modes	Auto, Flash off, Flash on, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	0.0005 s
Flash range (tele)	1 - 2 m
Flash range (wide)	0.5 - 3.5 m
Flash exposure correction	±2EV (1/3 EV step)
Video resolutions	320 x 240, 640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supported	MP4
Maximum video resolution	1920 x 1080 pixels
Resolution at capture speed	1920x1080@30fps, 1920x1080@60fps, 640x480@30fps
Audio formats supported	AAC
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Vari-angle LCD display	No
Display resolution (numeric)	922000 pixels
USB version	2.0
USB connector	Mini-USB B
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Fireworks, Portrait, Snow, Sports
Photo effects	Black&White, Neutral, Positive film, Sepia, Skin tones, Vivid
White balance	Auto, Cloudy, Custom modes, Daylight, Fluorescent, Fluorescent H, Tungsten
Self-timer delay	2, 10 s
Languages support	Multi
Camera file system	DPOF 1.1, Exif 2.3
Playback zoom (max)	10 x
Mac operating systems supported	Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Power source type	Battery
Battery type	NB-6LH
Battery life (CIPA standard)	250 shots
Product color	Black
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Bundled software	ImageBrowser EX, PhotoStitch, Map Utility

Weight and Dimensions

Depth	34.8 mm
Width	112.7 mm
Height	65.8 mm
Weight	- g
Weight (including battery)	269 g
