Installing the Software
Windows 7 and Mac OS X 10.8 are used here for the sake of illustration.
What you will need:
 Computer
 USB cable (camera end: Mini-B)*
* A USB cable is not included. Although you can install the software without using a
cable, some features will not be added.
1 Download the software.
 With a computer connected to the
Internet, access http://www.canon.com/
icpd/.
 Access the site for your country or region.
 Download the software.
2 Begin the installation.
 Click [Easy Installation] and follow the
on-screen instructions to complete the
installation process.
3 When a message is displayed
prompting you to connect the
camera, choose whether to
connect or not.
When Connecting the Camera to
the Computer
 With the camera turned off, open the
cover (
). With the smaller plug of the
USB cable in the orientation shown,
insert the plug fully into the camera
terminal (
).
 Insert the larger plug of the USB cable
in the computer’s USB port. For details
about USB connections on the computer,
refer to the computer user manual.
 Turn the camera on, and follow the
on-screen instructions to complete the
installation process.
Without Connecting the Camera
 Select [Install without connecting
the device] and follow the on-screen
instructions to complete the installation
process.
COPY

Canon PowerShot SX700 HS Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Image sensor size	1/2.3 \
Image formats supported	JPG
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	4608 x 3456, 3264 x 2448, 2048 x 1536, 640 x 480, \\r 4608 x 2592, 3264 x 1832, 1920 x 1080, 640 x 360, \\r 4608 x 3072, 3264 x 2176, 2048 x 1368, 640 x 424, \\r 3456 x 3456, 2448 x 2448, 1536 x 1536, 480 x 480
Digital zoom	4 x
Optical zoom	30 x
Combined zoom	120 x
Focal length range	4.5 - 135 mm
Maximum aperture number	6.9
Minimum aperture number	3.2
Lens structure (elements/groups)	13/10
Maximum focal length (35mm film equiv)	750 mm
Minimum focal length (35mm film equiv)	25 mm
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	9
Auto focusing (AF) modes	Continuous Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance	0.01 m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	3200
ISO sensitivity (min)	100
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/3200 s
Slowest camera shutter speed	15 s
Flash modes	Auto, Flash off, Flash on, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	0.0005 s
Flash range (tele)	1 - 2 m
Flash range (wide)	0.5 - 3.5 m
Flash exposure correction	±2EV (1/3 EV step)
Video resolutions	320 x 240, 640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supported	MP4
Maximum video resolution	1920 x 1080 pixels
Resolution at capture speed	1920x1080@30fps, 1920x1080@60fps, 640x480@30fps
Audio formats supported	AAC
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Vari-angle LCD display	No
Display resolution (numeric)	922000 pixels
USB version	2.0
USB connector	Mini-USB B
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Fireworks, Portrait, Snow, Sports
Photo effects	Black&White, Neutral, Positive film, Sepia, Skin tones, Vivid
White balance	Auto, Cloudy, Custom modes, Daylight, Fluorescent, Fluorescent H, Tungsten
Self-timer delay	2, 10 s
Languages support	Multi
Camera file system	DPOF 1.1, Exif 2.3
Playback zoom (max)	10 x
Mac operating systems supported	Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Power source type	Battery
Battery type	NB-6LH
Battery life (CIPA standard)	250 shots
Product color	Black
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Bundled software	ImageBrowser EX, PhotoStitch, Map Utility

Weight and Dimensions

Depth	34.8 mm
Width	112.7 mm
Height	65.8 mm
Weight	- g
Weight (including battery)	269 g
