Canon PowerShot SX700 HS User Manual

Before Use
Basic Guide
Advanced Guide
Camera Basics
Auto Mode / Hybrid
Auto Mode
Other Shooting
Modes
P Mode
Tv, Av, and M Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
47
Before Use
Basic Guide
Advanced Guide
Camera Basics
Auto Mode / Hybrid
Auto Mode
Other Shooting
Modes
P Mode
Tv, Av, and M Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Still Images
Red-Eye Correction
Red-eye that occurs in ash photography can be automatically corrected as
follows.
1 Access the [Flash Settings]
screen.
 Press the <n> button, choose [Flash
Settings] on the [4] tab, and then press
the <
m
> button (=
24).
2 Congurethesetting.
 Choose [Red-Eye Corr.], and then
choose [On] (=
25).
 Once the setting is complete, [R] is
displayed.
 To restore the original setting, repeat this
process but choose [Off].
• Red-eye correction may be applied to image areas other than eyes (if
the camera misinterprets red eye makeup as red pupils, for example).
• You can also correct existing images (= 109).
• You can also access the screen in step 2 when the ash is up by pressing the
<r> button and immediately pressing the <n> button.
Still Images
Correcting Greenish Image Areas from
Mercury Lamps
In [ ] mode, subjects or background in shots of evening scenes
illuminated by mercury lamps may appear to have a greenish tinge. This
greenish tinge can be corrected automatically when shooting, using Multi-
area White Balance.
 Press the <n> button, choose [Hg
Lamp Corr.] on the [4] tab, and then
choose [On] (=
24).
 Once the setting is complete, [ ] is
displayed.
 To restore the original setting, repeat this
process but choose [Off].
• After you are nished shooting under mercury lamps, you should set
[Hg Lamp Corr.] back to [Off]. Otherwise, green hues not caused by
mercury lamps may be corrected by mistake.
• Try taking some test shots rst to make sure you obtain the desired results.
• In continuous shooting (=
39), this setting is set to [Off] and cannot be
changed.
COPY

Canon PowerShot SX700 HS Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Image sensor size	1/2.3 \
Image formats supported	JPG
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	4608 x 3456, 3264 x 2448, 2048 x 1536, 640 x 480, \\r 4608 x 2592, 3264 x 1832, 1920 x 1080, 640 x 360, \\r 4608 x 3072, 3264 x 2176, 2048 x 1368, 640 x 424, \\r 3456 x 3456, 2448 x 2448, 1536 x 1536, 480 x 480
Digital zoom	4 x
Optical zoom	30 x
Combined zoom	120 x
Focal length range	4.5 - 135 mm
Maximum aperture number	6.9
Minimum aperture number	3.2
Lens structure (elements/groups)	13/10
Maximum focal length (35mm film equiv)	750 mm
Minimum focal length (35mm film equiv)	25 mm
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	9
Auto focusing (AF) modes	Continuous Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance	0.01 m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	3200
ISO sensitivity (min)	100
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/3200 s
Slowest camera shutter speed	15 s
Flash modes	Auto, Flash off, Flash on, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	0.0005 s
Flash range (tele)	1 - 2 m
Flash range (wide)	0.5 - 3.5 m
Flash exposure correction	±2EV (1/3 EV step)
Video resolutions	320 x 240, 640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supported	MP4
Maximum video resolution	1920 x 1080 pixels
Resolution at capture speed	1920x1080@30fps, 1920x1080@60fps, 640x480@30fps
Audio formats supported	AAC
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Vari-angle LCD display	No
Display resolution (numeric)	922000 pixels
USB version	2.0
USB connector	Mini-USB B
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Fireworks, Portrait, Snow, Sports
Photo effects	Black&White, Neutral, Positive film, Sepia, Skin tones, Vivid
White balance	Auto, Cloudy, Custom modes, Daylight, Fluorescent, Fluorescent H, Tungsten
Self-timer delay	2, 10 s
Languages support	Multi
Camera file system	DPOF 1.1, Exif 2.3
Playback zoom (max)	10 x
Mac operating systems supported	Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Power source type	Battery
Battery type	NB-6LH
Battery life (CIPA standard)	250 shots
Product color	Black
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Bundled software	ImageBrowser EX, PhotoStitch, Map Utility

Weight and Dimensions

Depth	34.8 mm
Width	112.7 mm
Height	65.8 mm
Weight	- g
Weight (including battery)	269 g
