35
Basic Functions
Playback
E
Playing Back on a TV Screen
TVs with Audio/Video Terminals
Refer also to the TV or VCR instruction manual.
1. Turn off all devices before starting the connections.
2. Connect the STV-250N Stereo Video Cable to the camcorder’s AV
terminal and the audio/video terminals on the TV/VCR.
Connect the white plug to the white audio terminal L (left), the red plug to the red audio
terminal R (right) and the yellow plug to the yellow video terminal VIDEO.
3. If connecting to a TV, set the input selector to VIDEO. If connecting to
a VCR, set the input selector to LINE.
We recommend powering the camcorder from a household power source.
TVs with Video ID-1 system: Recordings made in the widescreen mode will be
automatically played back in widescreen mode.
VIDEO
AUDIO
L
R
Signal flow
STV-250N Stereo Video Cable
(supplied)
To Next Page
