8
2558 980 1800 2200 1000 385
2565 980 1850 2200 1000 385
3275 980 1816 2990 1000 689
3275 980 1940 2990 1000 689
NOTE: Refer to the certified dimensional drawings
supplied with the unit, when designing an installation.
30HXC-080
30HXC-090
30HXC-100
30HXC-110
AD
B
600
500
4
700
4
3
C
E
3
3
F
1
2
All dimensions are in mm.
Evaporator
Condenser
Clearances required for operation and maintenance
Clearances required for heat exchanger tube removal. Clearances D
and E can be either on the left or on the right hand side.
Water inlet
Water outlet
Power supply
1
2
3
4
