Carrier 30RA-900 050 Series User Manual

6
1' [305]
1' 5-13/32"
[442]
TANK
ACCESS
TANK
ACCESS
TANK
ACCESS
1' 1/16"
[306]
1' 5-13/32"
[442]
CHILLER MOUNTING SLOT
Ø2-1/2" VICTAULIC WATER
INLET/OUTLET
DETAIL A
AT (4) PLCS
Ø7/32" [6] X 1" [25] LG SLOT
SEE DETAIL A
1-1/2"
[38.1]
3" [76.2] MOUNTING HOLES, FOUR CORNERS (TYP)
A
4' 1-3/8" [1254]
CENTER OF GRAVITY
3' 7-31/32"
[1117]
MOUNTING HOLES
3' 7-31/32"
[1117]
A
3' 8-1/2" [1130]
CENTER OF GRAVITY
3' 8-3/32" [1120]
4' 6-5/8"
[1387]
2' 10-3/32"
[866]
2' 47/64"
[628]
TANK
ACCESS
TANK
ACCESS
TANK
ACCESS
CONTROL
BOX END
1' 10-7/8"
[581]
7' 4-31/32"
[2260]
CHILLER WATER OUT
FAR SIDE (REF)
2 X 12.02
[305.23]
2 X 22.94
[582.56]
2" SQ DRAIN
4 PLCS
CHILLER WATER IN
FAR SIDE (REG)
2 X 0' -1 1/6"
2 X 0' -4 7/8"
2 X 28.84
[732.43]
SECTION A-A
2 PLCS
CONTROL
BOX END
MOUNTING HOLES
Ø.88" (22.35) KNOCKOUT FOR
POWER TO THE CONTROL BOX
2 X 7' 5" [2260]
CHILLER MOUNTING SLOT
TANK
ACCESS
CONTROL
BOX END
Ø.88" (22.35) KNOCKOUT FOR
POWER TO THE CONTROL BOX
TANK
ACCESS
Ø.395/.405 (TYP)
MOUNTING HOLES,
MIDDLE EACH SIDE
TANK
ACCESS
8' 2-3/4"
[2508]
1/4" VENT
4 PLCS
2 X 22.90
[581.65]
2 X 12.06
[306.43]
4 X 14.07
[357.25]
4 X 7.03
[178.68]
TANK
ACCESS
TANK
ACCESS
TANK
ACCESS
C.B.
ACCESS
C.B.
ACCESS
Fig. 5 — Dimensions 30RA-900---052 (Unit Sizes 035-060)
NOTE: Dimensions are in inches [mm].
