SG-38MARB-01 Specifications subject to change without notice. 111
Compressor
NOTE: Remove the panel plate and PCB compressor connection before disassembling sound blanket.
Evacuate the system and confirm that there is no refrigerant
left in the system before removing the four-way valve and the
compressor. (For R32 & R290, you should evacuate the
system with the vacuum pump; flush the system with
nitrogen; then repeat the two steps before heating up the
brazed parts. The operation should be performed by an
authorized technician.
WAR N I N G
Procedure Illustration
1) Remove the terminal cover’s flange nut
and remove the terminal cover.
2) Disconnect the connectors.
Terminal Cover
To Next Page
