100
Optional Accessories For Installation ( Field Supplied ) (Cont.)
17.3 Front panel for Ducted Indoor unit size 12K
Front Panel
Item Part Name Qty
1 The panel border welding pieces 1
2 Panel right board 1
3 Display box assembly 1
4 Return air grille 2
5 Panel left board 1
6 Sponge 4
7 Display box mounting plate 1
8 Screws 14
9 Power cable clamp 1
10 Panel switch assembly 2
11 Return air up fixed grille 1
12 Screws 4
13 Filter support 1
14 Return air below fixed grille 1
To Next Page
